Anjielo Smart Home High Definition Anjielo Intelligent 6.8 Inch Control Panel for Home Automation with Scene Linking Features

$146.55 USD

Promotion Épuisé

Frais d'expédition calculés à l'étape de paiement.

Model AN-66081

Quantité

Anjielo Smart Home

Product Description

1.TF card: plug in an external TF card.
2. MICROUSB: external U disk; for upgrading
3. Microphone: for voice pickup.
4. Built-in 2W small speaker.
5. Wired network.
6. Power terminal: connect to AC220V power supply.
7.485 interface: Connect 485A+485B to control the background music through exter nal equipment. You can also control other 485 devices through this host
8. Trigger playback: connect to GND+ON to trigger playback of music.
9. Trigger the doorbell: connect to GND+DB to trigger the doorbell.
10. Audio input line: audio line (three-core shielded line: commonly known as microp hone line), RVVP2X0.5,RVVP2X0.75, connected to AUXL+AUXR+GND. External audio i nput.
11.Audio output: Audio cable (three-core shielded cable: commonly known as microp hone cable), RVVP2X0.5,RVVP2X0.75, connected to OUTR+OUTL+GND, can be connec ted to other power amplifiers.
12. Speaker: speaker cable(200 cores), RVH2X100,RVH2X200 connected to SPKL+SP KL-, the speaker is less than 30W.
13. Speaker: speaker cable (200 cores), RVH2X100,RVH2X200 connected to SPKL+SPKL-, the speaker is less than 30W.

Product Function Introduction

This host is connected to Tuya Smart Home. You can scan the code to bind this host through theTuya APP. After the binding is successful, you can control Tuya Smart Home.
2. Cortex1.5GHZ quad-core CPU,7-inch multi-touch capacitive screen, 1024*600IPS high-
definition resolution display; host system: Android 8.1 system.
3. Support mobile APP to control music and read text.
4.Support mobile APP to adjust the volume.
6. Support mobile phone APP to control music, stories, and manage host-related APPs.
7. Support the pairing of external Bluetooth devices such as mobile phones to realize audio playback, and can control the playback of music from external Bluetooth devices in two directions,and can set Bluetooth to be turned on or off.
8. Support background switching function.
9. Support screen saver customization function.
10. Support scene music one-key play function.
11. Support multi-segment timing to play music; set the time arbitrarily, and you can choose to start and play the specified song at regular time.
12. Support the function of restarting the host at regular time.
13. Support all kinds of Android software installation.
14.Support external devices to control the machine through 485.
15.Support audio input function.
16. Support audio output function.
17. Support TF card and MICRO2.0USB interface, USB can be connected to external hard disk; 18. Support TF card firmware upgrade;
19. Support OTA online upgrade.
20.Built-in WIFI wireless connection, which can support external input control and output controlof external smart devices.

External Interface Description
